Smart farm
- Country DE, Bayrischzell
- Build year 1890
- Area >500 m²
- LOXONE partner Maustronik GmbH
Challenge
The aim of this smart farm in Bavaria was to create a modern IT infrastructure. Energy and heating were a particularly important topic, as this project includes four heat pumps, a CHP unit, a wood chip boiler, a hay drying system and an internal local heating network.
Other components of the farm include 2 PV systems and a battery storage system. The main building was retrofitted using Loxone and the two other holiday flats have full smart home equipment. These include a sauna and a pool with a paddling pool for children. Particular attention was paid to the exterior lighting of the courtyard, and therefore also to the presentation of the building.
Other components of the farm include 2 PV systems and a battery storage system. The main building was retrofitted using Loxone and the two other holiday flats have full smart home equipment. These include a sauna and a pool with a paddling pool for children. Particular attention was paid to the exterior lighting of the courtyard, and therefore also to the presentation of the building.
Solution
A total of 6 Miniservers were installed, which interact perfectly with a further 400 Loxone components. A centralised energy management system for heating and electricity is also controlled and monitored using Loxone. Another highlight is the specially developed control parameters for the sauna and pool. The outdoor courtyard lighting was realised using several dimmer extensions and specially converted lanterns.
Loxone offers us incredible flexibility, which makes it superior to many other systems such as KNX.
Bernhard Padeller, Planning and project planning electronics
Products
- Miniserver · 100335
- Air Base Extension · 100114
- Smoke Detector Air · 100142
- RS485 Extension · 100011
- Modbus Extension · 100124
- Audioserver · 100428
- Dimmer Extension · 100029
- Nano DI Tree · 100242
- RGBW LED Strip 5m IP65 (splashproof) · 200099
- LED Pendulum Slim RGBW PWM White · 100274
- LED Spot RGBW PWM White Gen. 1 · 100204
- LED Ceiling Light RGBW Tree White · 100288
- RGBW LED Strip 5m IP20 (touch-safe) · 200098
- Room Comfort Sensor Air White (Temperature, Humidity) · 100264
- Presence Sensor Tree White · 100422
- Room Comfort Sensor Tree White (CO2, Temperature, Humidity) · 100276
- 1-Wire Extension · 100014
- Relay Extension · 100038
- Tree Extension · 100218
- AO Extension · 100382
- Stereo Extension · 100429
- Intercom Signal White · 100484
- Nano 2 Relay Tree · 100395
