array(24) {
  ["id"]=>
  int(4326)
  ["name"]=>
  string(34) "Port Massaluca Camping & Bungalows"
  ["slug"]=>
  string(32) "port-massaluca-camping-bungalows"
  ["challenge"]=>
  string(461) "We were contacted from Camping Port de Massaluca, a campsite with few plots and bungalows located in Tarragona because the director wanted to create a new concept of the "Boutique Camping" type, that is, due to its low occupancy, he wanted to make his stay a more comfortable for the user accompanied by quality services such as its spaces, restaurant and activities, hence I would like to automate the bungalows and at the same time make efficient use of them."
  ["solution"]=>
  string(1544) "Finally, 2 types of bungalows with different quality finishes were defined.



The basic bungalows integrate:



Lighting system using Loxone Tree technology and RGBW spot LEDs

· Consumption measurement: Through the Modbus Extension and Circutor energy meter.

· Air conditioning control: Through the Modbus Extension and Intesis gateway.

· Access control: Through NFC Code Touch and control of electric locks through the Relay extension.

· Conventional JUNG pushbuttons: Through the DI extension.

· Security: Through the Loxone Air Extension and Door & Window Contacts.

· Technical alarms: Through Smoke Detector Airs and water solenoid valve control

· Load management: Through Relay Extension, heater management.

· Thermostats: Digital home and Modbus physical wall thermostats



The fully equipped bungalows, in addition to the controls of the basic bungalow, include:



· Multiroom audio split up in 4 zones: Through the Audioserver and built-in speakers.

Blind control: Through Nano 2 Relay Trees

Pushbuttons: Through Touch Pure control buttons in anthracite

· Heating: By means of the Relay extension acting on the electrothermal heads.



All this is packaged in an intuitive way for the user through the Loxone App, and efficient management is possible for the Campsite managers, adding logic "Check in" "Check out", notifications, and different scenarios such as vacation or maintenance."
  ["partner_quote"]=>
  string(96) "The Loxone system fit the customer's requests for its integrability of all systems and its cost."
  ["partner_quote_name"]=>
  string(13) "Xavier Imaña"
  ["partner_quote_position"]=>
  string(13) "Administrator"
  ["more_info_url"]=>
  string(0) ""
  ["preview_image"]=>
  string(81) "https://portal.loxone.com/admin/wp-content/uploads/2022/10/1666799346-768x512.jpg"
  ["application_areas"]=>
  array(6) {
    [0]=>
    string(8) "lighting"
    [1]=>
    string(7) "shading"
    [2]=>
    string(7) "heating"
    [3]=>
    string(7) "cooling"
    [4]=>
    string(6) "access"
    [5]=>
    string(6) "energy"
  }
  ["tags"]=>
  array(0) {
  }
  ["project_type"]=>
  array(1) {
    [0]=>
    string(5) "hotel"
  }
  ["copyright"]=>
  NULL
  ["images"]=>
  array(5) {
    [0]=>
    array(2) {
      ["image"]=>
      string(82) "https://portal.loxone.com/admin/wp-content/uploads/2022/10/1666799346-1024x683.jpg"
      ["copyright"]=>
      string(34) "Port Massaluca Camping & Bungalows"
    }
    [1]=>
    array(2) {
      ["image"]=>
      string(82) "https://portal.loxone.com/admin/wp-content/uploads/2022/10/1666799392-1024x683.jpg"
      ["copyright"]=>
      string(34) "Port Massaluca Camping & Bungalows"
    }
    [2]=>
    array(2) {
      ["image"]=>
      string(82) "https://portal.loxone.com/admin/wp-content/uploads/2022/10/1666799438-1024x683.jpg"
      ["copyright"]=>
      string(34) "Port Massaluca Camping & Bungalows"
    }
    [3]=>
    array(2) {
      ["image"]=>
      string(82) "https://portal.loxone.com/admin/wp-content/uploads/2022/10/1666799586-1024x683.jpg"
      ["copyright"]=>
      string(34) "Port Massaluca Camping & Bungalows"
    }
    [4]=>
    array(2) {
      ["image"]=>
      string(82) "https://portal.loxone.com/admin/wp-content/uploads/2022/10/1666799618-1024x683.jpg"
      ["copyright"]=>
      string(34) "Port Massaluca Camping & Bungalows"
    }
  }
  ["country"]=>
  string(2) "ES"
  ["city"]=>
  string(9) "Tarragona"
  ["build_year"]=>
  string(4) "2021"
  ["square_meters"]=>
  string(6) "5x80m2"
  ["account_data"]=>
  array(4) {
    ["id"]=>
    string(36) "2fcbeb87-932c-4691-9cf5-8d81bd0da52d"
    ["name"]=>
    string(20) "INGENIUS DOMOTICA SL"
    ["website"]=>
    string(0) ""
    ["partner_website"]=>
    string(46) "/partner/08027-barcelona/ingenius-domotica-sl/"
  }
  ["conference"]=>
  string(4) "none"
  ["products"]=>
  array(12) {
    [0]=>
    array(2) {
      ["sku"]=>
      string(6) "100038"
      ["name"]=>
      string(15) "Relay Extension"
    }
    [1]=>
    array(2) {
      ["sku"]=>
      string(6) "100114"
      ["name"]=>
      string(18) "Air Base Extension"
    }
    [2]=>
    array(2) {
      ["sku"]=>
      string(6) "100124"
      ["name"]=>
      string(16) "Modbus Extension"
    }
    [3]=>
    array(2) {
      ["sku"]=>
      string(6) "100142"
      ["name"]=>
      string(18) "Smoke Detector Air"
    }
    [4]=>
    array(2) {
      ["sku"]=>
      string(6) "200113"
      ["name"]=>
      string(28) "Door & Window Contact Sensor"
    }
    [5]=>
    array(2) {
      ["sku"]=>
      string(6) "100014"
      ["name"]=>
      string(16) "1-Wire Extension"
    }
    [6]=>
    array(2) {
      ["sku"]=>
      string(6) "100395"
      ["name"]=>
      string(17) "Nano 2 Relay Tree"
    }
    [7]=>
    array(2) {
      ["sku"]=>
      string(6) "100422"
      ["name"]=>
      string(26) "Presence Sensor Tree White"
    }
    [8]=>
    array(2) {
      ["sku"]=>
      string(6) "100462"
      ["name"]=>
      string(26) "Touch Pure Tree Anthracite"
    }
    [9]=>
    array(2) {
      ["sku"]=>
      string(6) "100480"
      ["name"]=>
      string(30) "NFC Code Touch Tree Anthracite"
    }
    [10]=>
    array(2) {
      ["sku"]=>
      string(6) "100497"
      ["name"]=>
      string(25) "Install Speaker 7 Passive"
    }
    [11]=>
    array(2) {
      ["sku"]=>
      string(6) "100334"
      ["name"]=>
      string(29) "LED Spot RGBW Tree Anthracite"
    }
  }
  ["video"]=>
  string(0) ""
  ["fallback"]=>
  array(8) {
    ["name"]=>
    string(34) "Port Massaluca Camping & Bungalows"
    ["challenge"]=>
    string(461) "We were contacted from Camping Port de Massaluca, a campsite with few plots and bungalows located in Tarragona because the director wanted to create a new concept of the "Boutique Camping" type, that is, due to its low occupancy, he wanted to make his stay a more comfortable for the user accompanied by quality services such as its spaces, restaurant and activities, hence I would like to automate the bungalows and at the same time make efficient use of them."
    ["solution"]=>
    string(1544) "Finally, 2 types of bungalows with different quality finishes were defined.



The basic bungalows integrate:



Lighting system using Loxone Tree technology and RGBW spot LEDs

· Consumption measurement: Through the Modbus Extension and Circutor energy meter.

· Air conditioning control: Through the Modbus Extension and Intesis gateway.

· Access control: Through NFC Code Touch and control of electric locks through the Relay extension.

· Conventional JUNG pushbuttons: Through the DI extension.

· Security: Through the Loxone Air Extension and Door & Window Contacts.

· Technical alarms: Through Smoke Detector Airs and water solenoid valve control

· Load management: Through Relay Extension, heater management.

· Thermostats: Digital home and Modbus physical wall thermostats



The fully equipped bungalows, in addition to the controls of the basic bungalow, include:



· Multiroom audio split up in 4 zones: Through the Audioserver and built-in speakers.

Blind control: Through Nano 2 Relay Trees

Pushbuttons: Through Touch Pure control buttons in anthracite

· Heating: By means of the Relay extension acting on the electrothermal heads.



All this is packaged in an intuitive way for the user through the Loxone App, and efficient management is possible for the Campsite managers, adding logic "Check in" "Check out", notifications, and different scenarios such as vacation or maintenance."
    ["partner_quote"]=>
    string(96) "The Loxone system fit the customer's requests for its integrability of all systems and its cost."
    ["partner_quote_name"]=>
    string(13) "Xavier Imaña"
    ["partner_quote_position"]=>
    string(13) "Administrator"
    ["more_info_url"]=>
    string(0) ""
    ["video"]=>
    string(0) ""
  }
}
