NEW: Loxone Config and App V11

29th April 2020 in Technology

Icon 01

System Schematic: Graphical representation of an installation

The new System Schematic Function block allows the graphical visualisation of systems, floor plans and more in the Loxone App. With this feature in Loxone Config, an image can be uploaded and you can then overlay Function Blocks onto the image to correlate. You can really let your imagination free with this feature!

Here you can find an example of what we have used the System Schematic block for. Let yourself be inspired and send us a screenshot of your system diagram to [email protected] so that we can expand the gallery.

Icon 02

Daylight Responsive Lighting Controller: For constant lighting levels

Especially in commercial rooms and offices, there is often a need for constant light levels. This is the daylight-dependent control of artificial light sources, with reference to any natural light already available, with the aim of maintaining a constant light level.

With this new Function Block, Loxone Partners can now implement daylight responsive lighting control with even greater ease. All you need is a brightness sensor that is well-positioned in the room, then simply specify the desired minimum lux value and the desired adjustment rate – that’s it.

Bausteine Brightness Controller
Icon 03

SIA DC-09 Support*

SIA DC-09 is one of the world’s most widely used digital communication protocol standards for transmitting information about a hazardous situation to a control centre, such as an alarm being triggered and a signal being sent to a central control station. Using the SIA DC-09 function, the Loxone Miniserver can now send a signal, including a predefined message, to an SIA server.

Screenshot SIA Einstellungen

* This function requires the second generation Miniserver. (100335)

Icon 04

Emergency Alarm:
Alerting you to critical situations

This Function Block is used to send a call for help in emergency situations. It not only offers new application possibilities in the field of AAL (Ambient Assisted Living) but can also provide important assistance in many other critical situations – such as the robbery of a corner shop or similar.

With this Function Block, you can quickly and easily implement an emergency button. If any button is pressed for a freely-definable period of time, the system sends an automated emergency call. This phone call can then simultaneously inform the receiver of the name or location of the triggering button or the name of the user.

Baustein Emergency Alarm
Icon 05

Paket- und Postkasten:
Benachrichtigung für Post und Pakete

Mit dem neuen Baustein werden Benutzer umgehend über die Zustellung von Paket- und Postsendungen informiert. Dank Loggingfunktion wissen Ihre Kunden nicht nur ob, sondern auch wann eine Sendung geliefert wurde.

Durch die zwei separaten Eingängen für Paket- bzw. Postsendungen, können die Meldungen unabhängig voneinander getriggert bzw. quittiert werden.

Tipp: Kennen Sie schon unser Kooperationsprodukt den Paketsafe Air? Mit ihm bieten Sie Ihren Kunden eine intelligente Lösung, um Pakete sicher zu empfangen, auch wenn sie nicht zu Hause oder im Büro sind.

Baustein Post und Paketkasten
Icon 06

New Permission Management
for Users and User Groups

Thanks to the new User Management features, you can now coordinate the members of a User Group even more easily and quickly. You can use the new dialogue box to manage the authorisations of individual Users and User Groups more intuitively. The new function also gives you more choice in customising the visualisation, authorising access, as well as external and internal access to the Miniserver – giving you more options to meet the individual needs of your customers.

Screenshot Berechtigungsverwaltung
Icon 07

Remote Connect*:
End-to-end encryption between App, Loxone Config and Miniserver

The “Remote Connect” service is a new free service for the Miniserver Generation 2, activated with just a click in the Miniserver’s network settings. The service enables a secure connection between the Miniserver and App or Loxone Config. You and your customers don’t have to worry about external approvals, port forwarding or the like anymore. Plus, thanks to end-to-end encryption the service is also highly secure.

Screenshot Remote Access

* This function requires the second generation Miniserver. (100335)

Icon 08

Audio Zone:
Completely redesigned
new music interface

We have completely redesigned the visualisation for audio zones! The intuitive interface is now clearer, more powerful and streamlined. Some of the new features include:

Revised favourites and user options
Loxone App Favoriten
Simplified and streamlined layout
Loxone App Playlist
Centralised search
Loxone App Suche
Icon 09

Apple Watch Support

Your customers can now control their home or building from their wrist! Quick Actions that you set up on your iPhone are now automatically available in the Loxone App for Apple Watches!

” Requires watchOS 6 or greater

Apple Watch
Icon 10

Helpful Text within the Loxone App

Directly from within Loxone Config or using Expert Mode in the Loxone App, it is now possible to add freely-defined snippets of text for a Function Block. These snippets can then serve as fantastic helpful notes for your customers when called up in the Loxone App.

In this way, you can provide your customers with information about the installation, about how to use a specific feature, a reminder on what a feature does, and more – ultimately improving the user-friendliness of their smart installation.

Loxone App Hilfe
Icon 11

New features for the Touch Surface

With the five LEDs of the Touch Surface now being a separate input, you are now able to freely assign them! You can, once again, let your imagination free with this neat feature. You can continue to use the T5 inputs freely, and now also choose what the LEDs indicate…such as the current volume level or as a countdown timer. Let us know what unique use you have found with this new option!

Icon ...

…and much more!

In addition to the above, there are many more new and innovative features and improvements, such as:

  • LiveView: Manual value changes for outputs
  • Pairing dialogue box for Tree and Air devices is improve
  • Redesign of the periphery window for a better overview
  • Usability enhancements for the NFC Code Touch
  • New Modbus Templates
  • Improved help function within Loxone Config
  • More improvements for the Planning Tool
  • Greater security: Miniserver Gen.2 now uses TLS 1.2
  • Properties windows offer improved navigation
Wordcloud Features Config 11

Download Loxone Config V11
